$99.95

3 Phase Inverters

Master 3 Phase Inverter Diagnostics. Join Dave Hobbs for a clear, hands-on look at 3 Phase AC inverters and DC-to-DC converters used in hybrid and EV systems. Learn key electrical concepts, inverter components, and essential scan tool PIDs to boost your diagnostic skills.

Click for more information
SKU: LBT-436 Category: Tag: Brand:

About our 3 Phase Inverters

In this course, instructor Dave Hobbs will discuss 3 Phase AC inverters, along with the role DC to DC converters play in the 3 Phase process. A hands-on demonstration of the important scan tool PIDs involved in 3 Phase diagnostics is included.

Upon completion of this course, the participant will be able to:

  • Relate Ohm’s Law & Watt’s Law to 3 Phase AC
  • Describe the DC to AC Inversion Process
  • Explain the Important Components of 3 Phase AC Production
  • Interpret Symbols Used in 3 Phase Schematics
  • Describe the Main 3 Phase Diagnostic PIDs

Topics covered include:

  • Basics of Ohm’s Law & Watt’s Law
  • DC to DC Converters
  • DC to 3 Phase AC inverters
  • 3 Phase Production in Hybrid and EVs
  • Scan tool 3 Phase PIDs

Runtime: 46 minutes
Credit Hours: 1.0
