$99.95

Hybrid/EV Scan Tool Diagnostics

Master Hybrid and EV diagnostics with expert Andy Tirado and learn to navigate scan tool data, PIDs, and service modes. Gain the skills to monitor high-voltage batteries, inverters, and thermal management systems effectively. Enhance your ability to diagnose, repair, and maintain HEV/EV systems with confidence.

Click for more information
SKU: LBT-448 Category: Tag: Brand:

About our Hybrid/EV Scan Tool Diagnostics

Join AVI instructor Andy Tirado while he takes you through HEV/EV systems and their configurations. What are known areas to monitor to improve your diagnostic approach using a scan tool. Descriptions of known desired values, PID analysis, bi-directional commands, the importance of thermal management, and service mode to lead you down the proper path towards repair.

Topics Covered:

  • Service mode for ICE override
  • Module data navigation
  • Hybrid configuration identification
  • Proper HEV/EV service procedures
  • HEV/EV diagnostics

Objectives:

Upon completion participants will be able to:

  • Identify Hybrid Configurations
  • Describe High Voltage Battery Monitoring
  • Describe Inverter/Convertor Monitoring
  • Understand High Voltage Electric A/C
  • Understand Bi-directional Commands and Service Modes

Runtime = 52 minutes
Credit Hours = 1.5
